PRO-SOFT 5

Software for the projection of outlines and templates using CAD-PRO laser projectors

LAP control software to provide projection data, organize workflows and streamline production processes

PRO-SOFT 5 laser projection software

PRO-SOFT 5 is the user-friendly operating environment for your laser projection system. The new look and feel of the graphical user interface is easy to learn and easy to handle as it follows the current WINDOWS© 10 design. In addition, you may change parts of the configuration, the scaling and the skin individually. Frequently used functions are always visible, only occasionally used settings are found in submenus. This way the workers can focus on the most important parts of the processes - as few functions as possible, but as many as necessary.

Features of PRO-SOFT 5 laser projection software

Flexible data import

PRO-SOFT supports all common data formats used in the mentioned industries, as lpd, ply, dxf, IGES or others. We also provide import modules for STEP and Catia.

Embedded help

Context sensitive help offers short explanation and link to the requested topic in the manual.

Barcode integration

You may use a barcode reader to easily fill input fields of the software. Possible content may be user-ID, order number or the ID of the object to be displayed.

Operation by projected laser menu

Some important functions that up to now couldn‘t be addressed by remote control can now be handled directly on the workpiece surface using a projected laser menu. No need to walk to the PC.

Load balancing

Projection data is not distributed by position of the projectors, but by load. Projection areas have to overlap for optimal performance.

Switching between metric and imperial

PRO-SOFT 5 can operate in metric or imperial units. You may switch the unit selection in a running system, no restart required.

Variants of PRO-SOFT laser projection software

Feature	PRO-SOFT 5 TP	PRO-SOFT 5 UT	PRO-SOFT 5 ST	PRO-SOFT 5 MT
Context sensitive help	+	+	+	+
User management	+	+	+	+
Switching metric/imperial	+	+	+	+
Editor for display of text and icons	+	+	+	+
Brighter display of selected projection areas	+	+	+	+
Load balancing	+	+	+	+
Barcode readers supported	+	+	+	+
Logfiles and reports	+	+	+	+
Operation by projected laser menu	+	+	+	+
Display of object name	+	+	+	+
Rubberband digitizing	+
Manual change of z-coordinate	+	+
Manual change of y-coordinate		+
Compatible to Unitechnik format		+
Automatic load of updated files			+	+
Automated check of target positions			+	+
View from 6 angles and isometric			+	+
Client-Server architecture				+
Multitasking				+

PRO-SOFT 5 TP

PRO-SOFT 5 TP is the standard software for all works on a plane surface in combination with height coordinates. The height level of the projection (z-coordinates) can be changed
manually. For recurrent height values you may easily create buttons in the tool bar.

LAP PRO-SOFT TP template control software to provide projection data, organize workflows and streamline production processes

screenshot of LAP PRO-SOFT TP template projection control software — LAP PRO-SOFT TP template control software to provide projection data, organize workflows and streamline production processes

PRO-SOFT 5 UT

This software has been optimized for users in the concrete prefab industry. You can import and display data in Unitechnik format. Unitechnik data is displayed in the lower part of the screen. The software supports production of double-wall elements. Positions of reinforcements also can be shown.

LAP PRO-SOFT UT Unitechnik compatible control software to provide projection data, organize workflows and streamline production processes

screenshot of LAP PRO-SOFT UT projection control software — LAP PRO-SOFT UT Unitechnik compatible control software to provide projection data, organize workflows and streamline production processes

PRO-SOFT 5 ST

For projection on 3D surfaces PRO-SOFT ST is the right choice. The single tasking version can control complex work areas with up to 16 projectors. More projectors can be connected with customized solutions. Projectors may be placed with offset to each other, turned by 90°, facing each other or crosswise to cover contorted or twisted shapes.

LAP PRO-SOFT ST control software to provide projection data, organize workflows and streamline production processes

screenshot of LAP PRO-SOFT ST projection control software — LAP PRO-SOFT ST control software to provide projection data, organize workflows and streamline production processes

PRO-SOFT 5 MT

If you want to manage several independent work processes from one PC, you need the multitasking abilities of PRO-SOFT 5 MT. LAP is the only company offering projection software with a real client-server architecture. You may open several instances or connect several clients. Clients may be additional PCs, tablet PCs or handhelds, connected directly or via WLAN. Every client may start several instances of the software.

PRO-SOFT MT multitasking control software to provide projection data, organize workflows and streamline production processes

screenshot of LAP PRO-SOFT MT projection control software — PRO-SOFT MT multitasking control software to provide projection data, organize workflows and streamline production processes
