XtrAlign FD lasers

Stainless steel housing, red line, fixfocus, entry-level model for XtrAlign family

Xtra reliable industrial line lasers

XtrAlign FD series lasers are made for day to day use in tough industrial environment. Laser diode, electronic circuitry and precision optics are protected by a waterproof stainless steel housing. The laser diode has a service life of more than 30,000 hours. This means more than 10 years of operation if you use them 8 hours a day.

Key figures

0.1

mm/m laser line straightness

IP67

enclosure rating

IK10

impact resistance

>0

hours of service life

XtrAlign laser series

Become acquainted with the lasers of XtrAlign series and their special features.

Features of XtrAlign FD lasers

Precise laser lines

The bright red lines of LAP XtrAlign FD lasers always have a good visibility. Up to 30 mW laser power illuminate even long lines. The straightness of the line has a maximum deviation of 0.05 mm/m.

Virtually unbreakable

IK10 is the highest rating to define the resistance to impacts by kinetic energy. XtrAlign FD lasers have to withstand the impact of a 5 kg steel free fall hammer. 5 times. Tough enough?

Dust- and waterproof

You need lasers for use in the desert or offshore ? Try LAP XtrAlign series. The enclosure rating is IP67. One restriction only: obviously you have to keep the beam exit clean.

Configurations

XtrAlign FD line lasers

Model	Laser power	Line length*	Laser class @80°	@40°	@30°	@20°	@10°
LAP 1 FDL	1 mW	up to 1 m	1	1	1	1	1
LAP 3 FDL	1 mW	up to 2 m	1	1	2	2	2
LAP 5 FDL	1 mW	up to 4 m	1	2	2	2	2
LAP 10 FDL	1 mW	up to 6 m	2	2M	2M	2M	2M
LAP 15 FDL	1 mW	up to 10 m	2	2M	2M	2M	2M
LAP 30 FDL	1 mW	up to 20 m	2M	3R	3R	3R	3R

*standard optics, line length depends on ambient light, height above surface, angle

Technical data

Laser data

Laser type	diode
Wavelength	635 nm
Laser color	red
Divergence	0.5 mrad
Laser power	1 ... 30 mW

Electronics data

Operating voltage	12 ... 30 VDC
Power consumption	< 200 mA
Connector	M12, 4-core

Housing data

Dimensions	length 140 mm × ø 25 mm (front) / ø 20 mm (back)
Enclosure rating	IP67
Shock resistance	IK10
Temperature range	-10 ... 40°C (15 ... 105°F)
Humidity	35 ... 90% rel., non condensing
Weight	220 g

Laser data

Laser type	diode
Wavelength	635 nm
Laser color	red
Divergence	0.5 mrad
Laser power	1 ... 30 mW

Electronics data

Operating voltage	12 ... 30 VDC
Power consumption	< 200 mA
Connector	M12, 4-core

Housing data

Dimensions	length 140 mm × ø 25 mm (front) / ø 20 mm (back)
Enclosure rating	IP67
Shock resistance	IK10
Temperature range	-10 ... 40°C (15 ... 105°F)
Humidity	35 ... 90% rel., non condensing
Weight	220 g

Accessories for XtrAlign FD lasers

Brackets

B2-HD

B2-HD-K

B2-BKK-HD

B2-FD-J

B2-FD

B3-HD

B5-HD-F

B5-HD

Show all Show less

Power supply and connectors

Angled Connector 90° 24V

Power Supply for 24V lasers

Application examples for XtrAlign FD lasers

Wood industry

Positioning lasers and laser projection systems for alignment and positioning for the entire process chain of the woodworking industry

Tire building

Movable laser positioning systems for precise tire manufacturing on tire building machines and for quality control

Logistics

Laser positioning systems for marking security zones and positioning areas in logistics applications

Positioning lasers for lifting equipment

Our lasers provide visual positioning aid when handling goods with different types of cranes and hoists like coil lifters, grabs or tongs for coil handling.

Laser projectors for rotor blade manufacture

Laser projection systems for the precise alignment and positioning of molded parts and glass fiber plies during manual composite layup in wind rotor blade manufacturing
